BFC 3015+



Standard Configuration

The new generation of TruFiber

  • TruFiber is the ultimate fiber laser solution for all your cuttingneeds.
  • In fact, TruFiber delivers excellent process stability andconsistent process results.
  • Furthermore, the technology requires a minimum of maintenance.

Cutting Head
Precitec cutting unit with outstanding performance.
High cutting speed due to low weight.
Stable processing of thick materials.
Easy and quick maintenance.



CNC Control

FSCUT4000 is a widely used and proven laser cutting control
system that is designed for high speed and precision applications.
Advanced functions (e.g. automatic edge detection, break-point
memory, and power ramping) ensure high cutting quality and
efficiency. Overall, the FSCUT4000 provides a versatile and efficient
solution for laser cutting operations, improving productivity and
reducing material waste.

Maximum format size that can be processed

X-axis
: 3050 mm
Y-axis
: 1545 mm
Z-axis
: 260 mm

Workpiece

Max. weight (up to 6KW)
: 900 kg

Max. speed

Simultaneous
: m/min
Max. acceleration
: 1.7 g
Max. positioning speed
: 140 m/min

Accuracy

Positioning deviation
: ±0.03 mm/m
Average positioning
: ±0.03 mm
Cutting accuracy
: ±0.1 mm/m

Machine performance

CNC control
: FSCUT 4000
Time of table exchange
: 10 sec
Machine net weight
: 8000 kg

Laser Data

Max. power
: 3000 W
Cutting head
: Precitec LM
Wavelength
: 1071±2 um
Output type
: QBH
Output fiber optic diameter
: 100 um

Max. sheet thickness

Mild steel
: 22 mm
Stainless steel
: 16 mm
Aluminum
: 12 mm
Copper
: - mm
Brass
: 10 mm
